MBE.017021Monocular/Binocular/Trinocular Elementary Microscope, 40X~1000X
  • /usr/575/images/Products/Y/57519613.jpg
  • /usr/575/Picture/Y/11597.jpg
  • /usr/575/Picture/Y/11598.jpg
  •
  • Biological microscope, small size, three kinds of head for choosing.
  • It is very suitable for schools and scientific research institution.
Specification
MBE.017021-M
MBE.017021-B
MBE.017021-T
Head Monocular Head,
Inclined at 45o, 360o Rotatable
Seidentopf Binocular Viewing Head,
Inclined at 45o, Interpupillary 48-75mm
Seidentopf Trinocular Viewing Head,
Inclined at 45o, Interpupillary 48-75mm
Eyepiece
WF10x/18mm
Objective
Achromatic Objective 4x
Achromatic Objective 10x
Achromatic Objective 40x
Achromatic Objective 100x
Nosepiece
Quadruple Nosepiece
Focusing
Coaxial Coarse and Fine Adjustment, Moving Range 22mm
Stage
Double Layer Mechanical Rectangular Stage 140x130mm
Condenser
Abbe Condensor NA1.25 with Diaphragm, Filter
Illumination LED Light, Brightness Adjutable
Product Size 25*21.5*37cm

Item
Optional Accessories
Eyepiece WF16x/13mm
WF20x/11mm
Nosepiece Triple Nosepiece
Light 6V20W Halogen Lamp, Brightness Adjustment
