MBI.003047Inverted Microscope
  • /usr/575/images/Products/Y/57517691.jpg
  • /usr/575/Picture/Y/10736.jpg
  •
  •

Inverted Laboratory Biological Microscope

  • Excellent Optical Function with Infinitive Optical System.
  • Innovative Stand structure, Sharp Image Display, Convenient and Special for Viewing Incubating Cell Tissue.
Specification
MBI.003047
Head
Seidentopf Trinocular Head, 30° Inclined, Interpupillary 48~75mm, Diopter Adjustable
Optical System
Infinite optical system
Eyepiece
Extra Wide Field Eyepiece EW10x/22mm, High Eyepoint
Objective
Infinity Plan LWD Achromatic Objective 4x/0.1, W.D.18mm
Infinity Plan LWD Achromatic Objective 40x/0.6, W.D.2.6mm,Cover Glass 1.2mm
Infinity Plan Phase Contrast Achromatic Objective PH10x/0.25, W.D.10mm
Infinity Plan Phase Contrast Achromatic Objective PH20x/0.40, W.D.5.1mm
Nosepiece
Quintuple Nosepiece
Focusing
Coaxial Coarse & Fine Adjustment, Coarse Stroke 37.7mm Per Rotation, Fine Stroke 0.2mm Per Rotation
Stage

* Plain Stage 160*250mm
* Glass Insert Plate
* Auxiliary Stage 70*180mm

Condenser
ELWD Condenser N.A.0.3, Long Working Distance 72mm, Up to 150mm Without Condenser
Phase Contrast
* Centering Telescope, Tube Dia.30mm
* Phase Contrast Slide, 2 Holes For 10x-20x Objective
Filters
Green, Blue, Ground Glass, Dia.45mm
Illumination
External Kohler Illumination, Halogen Lamp 6V30W, Brightness Adjustable

Item
Optional Accessories
Wokring Stage
Attachable Mechanical Stage, X-Y Coaxial Control, Moving Range 120*78mm
Terasaki Holder
Petri Dish Holder Dia.38mm
Slide Glass Holder Dia.54mm
Slide Glass Holder Dia.90mm
Objective
Infinity Plan LWD Achromatic Objective 10x/0.25,W.D.10mm
Infinity Plan LWD Achromatic Objective 20x/0.4,W.D.5.1mm
Adapter


Photo Adapter
C-Mount 1.0x
C-Mount 0.5x
Fluorescent
Fluorescent Attachment
