MBI.001008Inverted Microscope
  • /usr/575/images/Products/Y/57517862.jpg
  • /usr/575/Picture/Y/10960.jpg
  • /usr/575/Picture/Y/10961.jpg
  •
  • Wide field eyepiece, long working distance, plan achromatic objectives
  • Coaxial coarse/fine focus system with tensional adjustable and up stop, minimum division of fine focusing 2um
  • 6V 30W halogen lamp with brightness control

Specification
MBI.001008
Eyepiece
Wide field WF10X(Φ22mm)
Centering telescope
Head
Inclination angle is 45Degree interpupillary distance is 53~75mm.
Infinity, Long Working Distance Plan Achromatic Objective
PLL 10X0.25 Work distance:4.3 mm,Cover glass thickness:1.2mm
PLL 20X0.40 Work distance:8.0 mm,Cover glass thickness:1.2mm
PLL 40X0.60 Work distance:3.5 mm,Cover glass thickness:1.2mm
PLL 10X0.25 PHP2 Work distance:4.3 mm,Cover glass thickness:1.2mm .Phase Contrast Objective
Shelf of Specimen
Match to installΦ68mm, or 77x29mm culture utensil
Match to install 82x57mm culture utensil
Match to install 128x85mm 96 holes culture utensil
Focus System
Coaxial coarse/fine focus system, with tensional adjustable and limit stopper, minimum division of fine focusing: 2 μm
Nosepiece
Quintuple
Stage
Fixed stage overall size is 227mmX208mm
Glass rotundity stage overall size Dia:118mm
Mechanical moving device, moving range is 77mm (longitudinal)X114mm (transverse)
Culture dish holder 1
Inside locating slot size: 86mm (W)X129.5mm (L), optional with a circular culture dish Dia 87.5mm
Culture dish holder 2
Inside locating slot size: 34mm (W)X77.5mm (L), optional with a circular culture dish Dia 68.5mm
Culture dish holder 3
Inside locating slot size:57mm (W)X82mm (L)
Filter
Blue filter
Green filter
Frosted filter
Light Source
6V30W halogen, brightness enable control
Sliding Phase Contrast Unit
Centering telescope
10x impellent style phase plate
Condenser rack & pinion adjustable, NA=0.4, working distance 30mm

Item
Optional Accessories
Eyepiece
Dividing eyepiece10x(field number:Φ22mm) 0.10mm/Div
Nosepiece
Sextuple nosepiece
Phase Contrast Objective
PL L20X/0.40 PHP2 Work distance8.0 mm
PL L40X/0.60 PHP2 Work distance3.5 mm
CCD Adapter
0.5x
1x
DC Adapter
For Canon ditigal camera adapter (A610, A620, A630, A640)
