MBM.003063Mutiple Viewing,3 pcs Head,40X~1000X
  • /usr/575/images/Products/Y/57517716.jpg
  •
  •
  •

Multi-Viewing , 3 Position!

Specification
MBM.003063
Head

1 pcs Sliding Binocular Head, 30°Inclined, Interpupilary Distance 55-75mm
2 pcs Monocular Head, 30°Inclined,

Eyepiece

WF10X, 4 pcs

Objective
Achromatic Objectives 4×
Achromatic Objectives 10×
Achromatic Objectives 40×(s)
Achromatic Objectives 100×(s,oil)
Nosepiece
Quadruple Revolving Nosepiece
Focusing
Coaxial Coarse & Fine Focusing Knobs, Fine division 0.002mm, Coase Stroke 37.7mm Per Rotation, Ffine Stroke 0.2mm Per Rotation, Moving Range 28mm
Stage
Double Layer Mechanical Stage 140mm x 140mm, Travel Range 75x50mm
Condenser
Abbe N.A.=1.25 with Iris Diaphragm & Filter
Illumination
Base with Built-in Halogen Lamp 6V/20W , with Continue Intensity Control, 110V/220V
