MMU.003044Upright Metallurgical Microscope
  • /usr/575/images/Products/Y/57517754.jpg
  •
  •
  •

The Microscope is widely used for PCB board, LCD display and metal structure observation and inspection. With Ingenious stand and convenient operation, it will be your best choice.

  • Excellent infinite Optical System. High Magnification Objective with Long Working Distance (up to 3.7mm for40X Objective)
  • Comfortable and Enjoyable Operation With low and Repetitive Position Control knob
  • Triangle Structure Make it much steadier and less working Space Occupation
  • Easy, Safe and Reliable Lamp Replacement Device

Specification
MMU.003044-24
MMU.003044-34
Head
Binocular Head
Trinocular Head
Optical System
Infinite optical system
Eyepiece
WF10x/18
Objective
Infinity Plan Achromatic Objectives 4×/0.1/∞/- WD25.4mm
Infinity Plan Achromatic Objectives 10×/0.25/∞/- WD11.0mm
Infinity Plan Achromatic Objectives 40×/0.60/∞/0 WD3.7mm
Nosepiece
Quadruple Nosepiece
Focusing
Coaxial Fine & Coarse Adjustment
Stage
Double layer mechanical stage150×140mm/75×50mm
Condenser
Abbe condenser NA.1.25 with aperture diaphragm
Filters
Blue,Green,Yellow ,Ground Glass
Illumination
Kohler Illumination, Epi-illuminator with iris aperture diaphragm and iris field diaphragm, 6V/20W Halogen Lamp, Brightness Adjustable

Item
Optional Accessories
Eyepiece
 WF8x/18
WF12.5x/15
WF10x/18 with 0.1mm Micrometer & Cross Hair
Objective
Infinity Plan Achromatic Objectives 20x/0.40/∞/- WD6.0mm
Infinity Plan Achromatic Objectives 40x/0.65/∞/- WD0.78mm
Infinity Plan Achromatic Objectives 50x/0.75/∞/- WD0.32mm
Infinity Plan Achromatic Objectives 80x/0.90/∞/- WD0.2mm
Infinity Plan Achromatic Objectives 100x/0.90/∞/0 WD0.7mm
Polarizing
Simple Polarization Set
Other
Specimen Presser For metallurgical specimen preparation
