MMI.023071Trinocular Inverted Metallurgical, 50X~500X
  • /usr/575/images/Products/Y/57518566.jpg
  • /usr/575/Picture/Y/11465.jpg
  •
  •
  • Professional metallurgical objective and plan eyepiece provide clear image, high resolution, comfortable observation.
  • Superior image and reliable mechanical structure.
  • With the corresponding photo or video accessories, can collect and preserve the image, with computers and specialized metallographic analysis software can analysis the metallographic image.
  • Easy to operate, Have all kinds of accessories. Widely used in teaching and research metallographic analysis, semiconductor silicon wafer inspection, geology mineral analysis, precision engineering and surveying fields.
Specification
MMI.023071
Head
Compensation Free Trinocular Head, 45° Inclinded, 360° Rotatable, Interpupillary Distance 54~75mm, Diopter Adjustable, Light Split 8:2
Eyepiece High Eyepoint Plan PL10x/18mm
Objective
Long Working Distance Plan Metallurgical Achromatic LMPL5X/0.15
Long Working Distance Plan Metallurgical Achromatic LMPL10X/0.3
Long Working Distance Plan Metallurgical Achromatic LMPL20X/0.4
Long Working Distance Plan Metallurgical Achromatic, Semi-APO 50X/0.6
Nosepiece
Backward quadruple nosepiece
Focusing

Low Position Coaxial Coarse & Fine Focusing, Coarse Focus Range 38mm, Fine Focusing Precision 0.002mm, with Tension Adjustment,with Up-limited Stop

Stage
  • Triple Layer Working Stage, Size 180*155mm, Moving Range 75*40mm
  • Metal Plate, Center Hole Dia.25mm
  • Metal Plate, Center Hole Dia.12mm
Condenser
Swing-out Condenser N.A.0.7, for Transmit Light
Filter Blue Filter, Dia.32mm
Illumination Reflect Kohler Illumination, with View Field Diaphragm, with Iris Diaphragm, Center Adjustable, 5W LED, Warm Light, Brightness Control
Power
90-240V Wide Range Power Supply

Item
Optional Accessories
Eyepiece


Wide Field Eyepiece WF15x/13mm
Wide Field Eyepiece WF20x/10mm
Wide Field Eyepiece WF15x/13mm with Retical
Wide Field Eyepiece WF20x/10mm with Retical
High Eyepoint Plan PL10x/18mm, with Cross PL10x18
Objective Long Working Distance Infinity Plan Metallurgical Achromatic,Semi-APO LMPL100X/0.8
Polarization Set
Analyser,360° Rotatable
Polarizer
Filter
Yellow,Dia.32mm
Green,Dia.32mm
Netural,Dia.32mm
Adapter
1.0x C-Mount
0.5x C-Mount, for 1/2" CCD
Photo Adapter with 3.2x Photo Eyepiece, PK or MD Mount
Digital Camera Adapter with Photo Eyepiece
