MFU.001003Upright Fluorescent Microscope
  • /usr/575/images/Products/Y/57517799.jpg
  • /usr/575/Picture/Y/10861.jpg
  • /usr/575/Picture/Y/10862.jpg
  •

Reflected fluorescence microscope

MFU.001003 Reflected fluorescence microscope model is used for fluorescence microscopy and transmitted bright field microscopy observation. It is the ideal instrument in sediment in sedimentary rock, inspection of impurity of semiconductor, environmental protection and microchemistry etc. It is the ideal instrument in biology, cytology, oncology, genetics, immunology etc. It also can be used in scientific research, universities, medical treatment, epidemic prevention etc.

  • With wide field eyepieces and achromatic objectives, the field of view is widely and clear
  • Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm
  • 6Volt 20Watt Halogen lamp with brightness control
Specification
MFU.001003
Eyepiece
Wide field WF10X (Φ18mm)
Eyepiece Tube
Trinocular (Inclination of 30°)
Objective
Achromatic 4X/0.10
Achromatic 10X/0.25
Achromatic 100X/1.25(Spring, oil)
Fluorescence 25X/0.65
Focus System
Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm
Nosepiece
Quadruple(Backward ball bearing inner locating
Stage
Double layer mechanical (Size:135mmX125mm, Move range: 75mmX35mm)
Abbe Condenser
N.A.1.25 Rack & pinion adjustable
Filter
Blue filter
Frosted filter
Collector
For halogen lamp
Light Source
6V 20W halogen lamp, adjustable brightness
Reflected Fluorescence System
Mercury lamp house 100W/DC
Power supply unit:AV:110V or 220V
Fluorescence filter system B exciton wavelength:420~485nm
Fluorescence filter system G exciton wavelength:460~550nm

Item
Optional Accessories
Eyepiece
Wide field eyepiece WF16X/11mm
Dividing 10X/20mm, 0.1mm/Div
Objective

Fluorescence objectives FL 40X/1.00 (Spring, Glycerin)
Fluorescence objectives FL 100X/1.25 (Spring, Glycerin)
Fluorescence
100W fluorescence power supply(wide voltage and constant power and calculagraph)
Reflected Fluorescence
Fluorescence filter system UV exciton wavelength:330~400nm
Fluorescence filter system V exciton wavelength:395~415nm
Nosepiece
Quintuple (Backward ball bearing inner locating)
Filter
Green filter
Yellow filter
Phase Contrast Unit
Eyepiece: centering telescope
Phase contrast plan achromatic objective 10X/0.25 PHPl)
Phase contrast plan achromatic objective 20X/0.40 PHP
Phase contrast plan achromatic objective 40X/0.65 PHP(Spring)
Phase contrast plan achromatic objective 100X/1.25 PHP(Spring, oil)
(PH-I) Turnplate phase contrast condenser
(PH-II) Turnplate phase contrast condenser
Flashboard phase contrast condenser
Pull board phase contrast condenser
CCD Adapter
0.4X
0.5X
1X
0.5X with dividing 0.1mm/Div
DC Adapter
Digital camera adapter CANON (A610,A620,A630,A640)
Photo Adapter
2.5X/4X Change over photograph adapter with 10X viewing eyepiece
4X Focusing photograph adapter
PK Adapter
MD Adapter
