MFI.001002Inverted Fluorescent Microscope

Inverted fluorescent microscope！

MFI.001002 Inverted fluorescent microscope is composed with Epi-fluorescent microscope and inverted microscope, equipped excellent UIS optical system and adopted long working distance plan achromatic objectives and wide field eyepieces. Compact and steady main frame body is embodiment for the shock resistance. The enable turning out or into condenser system is suited for observation in a high culture dish. The Epi-fluorescence microscope system is adopted modularization function design idea, so that adjust the fluorescence illuminating system and switching-over fluorescence filters safely and quickly.

This is a sort of ideal optical instrument for micro observation in cell tissue and transmitted liquid tissue, even in dynamic observation in the culture dish tissue, can be applied in the fluorescence microscopy, such as biological pharmacy, medicine checking and measure, disease prevent and etc.

Specification	MFI.001002
Eyepiece	Wide field WF10X(field number:Φ22mm)
	Centering telescope
Head	Inclination 45 Degree interpupillary distance is 53~75mm.
Objective	Infinity Plan Achromatic Objective, PLL 10x/0.25, WD 4.3mm, Cover Glass 1.2mm
	Infinity Plan Achromatic Objective, PLL 20x/0.40, WD 8.0mm, Cover Glass 1.2mm
	Infinity Plan Achromatic Objective, PLL 40x/0.60, WD 3.5mm, Cover Glass 1.2mm
	Phase Contrast Objective PLL10x/0.25 PHP2, WD 4.3mm, Cover Glass 1.2mm
	Phase Contrast Objective PLL20x/0.40 PHP2, WD 8.0mm, Cover Glass 1.2mm.
	Phase Contrast Objective PLL40x/0.60 PHP2, WD 3.5mm, Cover Glass 1.2mm
Focus System	Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm
Nosepiece	Quintuple nosepiece
Stage	Fixed stage overall size is 227mmX208mm
	Glass rotundity stage overall size Dia:118mm
	Mechanical moving device, moving range is 77mm (longitudinal)X114mm (transverse)
	Culture dish holder 1		Inside locating slot size: 86mm (W)X129.5mm (L), optional with a circular culture dish Ф87.5mm
	Culture dish holder 2		Inside locating slot size: 34mm (W)X77.5mm (L), optional with a circular culture dish Ф68.5mm
	Culture dish holder 3		Inside locating slot size:57mm (W)X82mm (L)
Epi-fluorescent illumination system	Power supply unit, 110V or 230V can be selected.
	100W/DC Mercury lamp is 100W/DC
	Fluorescent filters
	Group	Type	Wavelength of excitation light	Wavelength of emitted light
	UV+V	Ultraviolet light (UV)	330nm~400nm	425nm
		Violet light (V)	395nm~415nm	455nm
	B+G	Blue light (B)	420nm~485nm	515nm
		Green light (G)	460nm~550nm	590nm
Transmitted illumination system	Turnplate phase contrast condenser, working distance is 55mm
	6V30W halogen, brightness enable control
	Frosted glass and blue , green filter

Item	Optional Accessories
Eyepiece	10XDividing eyepiece(field number:\|μ22mm) 0.10mm/Div
Objective	Infinity plan achromatic objective PL 5X/0.12 W.D26.1
Nosepiece	Sextupe (Backward ball bearing inner locating)
CCD adapter	0.4X
	0.5X
	1X
	0.5Xwith dividing 0.1mm/Div
DC Aadapter	CANON(EF), NIKON(F)
