This LCD digital microscope is a bland new system that has an embedded system.With a 8.4” TFT screen, friendly man-machine interface, powerful processing function (real-time preview, dynamic calibrating and measuring), multiple peripheral interfaces, and comfortable mechanical design; it become a new generation microscope and easy to operate. So it is your good assistant in teaching, research and electronic checking!
|
Specification
|
MLB.003008
|
|
Head
|
Seidentopf Binocular Head, Inclined at 30°, Interpupillary Distance 52-75mm
|
|
Eyepiece
|
Wide Field Eyepiece EW10X/ 18
|
|
Digital Camera
|
2.0M CMOS Digital Camera Built-in
|
|
LCD Screen
|
8.4 Inch TFT Touching screen
|
|
Objective
|
Infinite Semi-Plan Achromatic Objective 4x
|
|
Infinite Semi-Plan Achromatic Objective 10x
|
|
|
Infinite Semi-Plan Achromatic Objective 40x
|
|
|
Infinite Semi-Plan Achromatic Objective 100x
|
|
|
Nosepiece
|
Backward Quadruple Nosepiece
|
|
Stage
|
Double Layer Mechanical Stage, Size 140×140mm, Moving Range 75×50mm
|
|
Condenser
|
Sliding-in Center Adjustable Condenser N.A.1.25
|
|
Focusing
|
Coaxial Coarse & Fine Adjustment, Moving Range 20mm
|
|
Output
|
USB2.0、AV and VGA Output, SD Card Slot, 100M Ethernet interface
|
|
Software System
|
Windows CE 5.0 Installed, Image Processing Software Installed, Can Capture, Record, Measure Image Easily
|
|
Mouse
|
Mouse & Keyboard Control Supported
|
|
Illumination
|
6V/ 20W Halogen Lamp Illumination, Adjustable Brightness
|
