MLB.003029LCD Biological Microscope, 9.7'' LCD, 5M, 40~1000X
  • /usr/575/images/Products/Y/57519026.jpg
  • /usr/575/Picture/Y/11623.jpg
  •
  •
  • 9.7’’ LCD Screen,resolution 1024*768
  • 5.0M CMOS Image Sensor built-in
  • Sharp Image Display with Excellent Optical Function.
  • Small Space Occupancy with Integral Stand Design, Low Environment Requirement with Anti-mould Technology.
  • Comfortable Operation with Ergonomic Design.
9.7" LCD Pad with Andriod System of MLB.003029
Specification of LCD PAD
LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU

1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System

RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser 1/2.5" CMOS, Color, Aptina MT9P001
Resolution
5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
MLB.003029-A
MLB.003029-B
Head
Seidentopf Binocular Head, Inclined at 30°
Eyepiece
Wide Field Eyepiece WF 10x/18
Magnification
40x~1000x
Objective
Achromatic Objectives 4X
Achromatic Objectives 10X
Achromatic Objectives 40X
Nosepiece
Achromatic Objectives 100X
Focusing Coaxial Coarse & Fine Adjustment, Coarse Stroke 37.7mm Per Stroke, Fine Stroke 0.2mm Per Rotation, Fine Division 0.002mm, Focusing Range 20mm
Stage
Double Layers Mechanical Stage 140mm×140mm/ 75mm×50mm
Condenser
N.A.1.25 Abbe Condenser with Iris Diaphragm and Filter
Filter Green Filter
Illumination
S-LED, Brightness Adjustable
Other
with Back Cover
