LCD Biological Microscope, 9.7" LCD, 5M, 40~1000X_IHPVISION:Microscope,Digital Vision

MLB.040003LCD Biological Microscope, 9.7" LCD, 5M, 40~1000X

9.7’’ LCD Screen,resolution 1024*768
5.0M CMOS Image Sensor built-in
High efficiency, flexibility, stability is a kind of biological microscope for all kinds of applications in the field of daily work and development. It can be widely used in a variety of laboratories, schools, hospitals.It is the first choice for individuals, schools, hospitals and scientific research units.
Wide field eyepiece, high brightness lighting system and high-quality optical components of high-definition imaging to high brightness;
Built-in converter and high quality objective lens, so that the user to operate with more convenient space and better observation effect;
Large mechanical platform and double plate specimen clip for observation and testing to provide convenient;
Accurate focusing mechanism and reasonable design of human nature to make the operator feel relaxed;
Front pull type set light mirror, let the user change the light bulb more quick and easy.
With 180*150mm big double layer mechanical stage

9.7" LCD Pad with Andriod System of MLB.040003
Specification of LCD PAD	LCD Screen	9.7" HD Diagonal IPS LCD Resolution 1024*768 Backlight Screen, Five Point Touch Screen, Hardware Power Switch
	CPU	1.6GHz Four Core ARM Mali-400 MP GPU Support OpenGL ES 1.1/2.0 And OpenVG 1.1 Support Full HD 1080p Support Android 4.2 System
	RAM	2GB, Support DDR3, DDR2, LPDDR2
	Data Storage	SD Card Slot, Support Max 32GB C10 High Speed SD Card
	Data Interface	HDMI, Mini USB2.0, USB 2.0
	Operation System	Android 4.2 System, Multi Language
	Power	Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor, Power Mode : Normal, Sleep, Power Off
	WIFI	Support
	Bluetooth	Support
	Software	YX Camera Installed, --Can Adjust Real Time Image --Can Measure Length, Area, Angle, Count --Can Take Picture, Record Video YX Image Installed --Grey, Contrast, Brightness Adjust --Binary Image For Granular Count Both Software Chinese/English Version, With Instruction Manual Installed
	Product Size	Pad 17.522.52.0cm
	Package Size	Packing Box 102429cm, 1 pc/Box
Specification of Digital Camera	Senser	1/2.5" CMOS, Color, Aptina MT9P001
	Resolution	5.0M Pixels, Maximum Photo Resolution 2592*1944
	Pixel Size	2.2um*2.2 um
	Effective Image Size	5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
	Frame Rate	1280720/15 Fps, 640480/30Fps
	Dynamic Range	66.5dB
	SNR	40.5dB Max
	ADC	12 Bit, On Chip
	Shutter Type	ERS, Auto
	White Balance	Auto
	Connect	Standard C-Mount Interface

Specification of Main Body

Specification	Main Body of MLB.040003
Head	Sliding Trinocular,45°inclined,52mm-74mm
Eyepiece	WF10X
Objective	Plan Achromatic Objective 4x
	Plan Achromatic Objective 10x
	Plan Achromatic Objective 40x,Spring,Oil
	Plan Achromatic Objective 100x,Spring,Oil
Nosepiece	Quadruple Revolving Nosepiece
Focusing	Coaxial Coarse and Fine Focusing with Rack and Pinion Mechanism; Fine Focusing Scale Value 0.002mm
Stage	Double Layer Mechanical Stage,Size180x150mm,Moving Range:75mmx50mm
Condenser	Abbe N.A.1.25Condenser with Iris Diaphragm & Filter
CCD Adapter	0.5x
Illumination	High Brightness Kohler Illumination, Halogen Bulb 12V/20W AC85V-230V, Adjustble Brightness
