Biological Digital Microscope, 0.3M/0.4M, 40X~1600X_IHPVISION:Microscope,Digital Vision

MDB.003004Biological Digital Microscope, 0.3M/0.4M, 40X~1600X

Digital microscope of integration, 1.3 M pixel digital camera system, clear image and real color reproduction
With professional image software for digital microscope, support multilingual operating system, including preview, taking photos or video, image processing and image measurement.
Friendly user interface, easy operation, the database of colour schemes also can be backuped.
Widely used in biology, histology, bacteriology etc.

Specification	MDB.003004-3U	MDB.003004-4UV
Camera System	CMOS Digital Camera 0.3M Pixel, USB1.0 Output	CCD Digital Camera 0.4M Pixel, RCA, S-Vide, USB2.O Output
Head	Seidentopf type Binocular Head, Inclined at 30°, Interpupilary Distance 55-75mm
Eyepiece	Wide Field Eyepiece WF10X/ 18
	Wide Field Eyepiece WF16X/ 11
Objective	Semi-plan Achromatic objectives 4x
	Semi-plan Achromatic objectives 10x
	Semi-plan Achromatic objectives 40x
	Semi-plan Achromatic objectives 100x
Nosepiece	Backward Quadruple Nosepiece
Stage	Double layers mechanical stage 140mm×140mm/ 75mm×50mm
Condenser	N.A.1.25 Abbe Condenser
Focusing	Coaxial coarse and fine adjustment
Filter	Blue Filter
	Green Filter
Illumination	1W Powerful LED Illumination, brightness adjustable

Item	Optional Accessories
Nosepiece	Backward Quintuple Nosepiece
Objective	Plan Achromatic Objective 4x
	Plan Achromatic Objective 10x
	Plan Achromatic Objective 20x
	Plan Achromatic Objective 40x
	Plan Achromatic Objective 60x
	Plan Achromatic Objective 100x
Illumination	Kohler Illumination
Software	ScopeImage Advanced Micro-image Process Software
Software	ScopeImage Analysis Software
Pointer	LED Pointer
Polarization Set	Simple Polarization Attachment
Dark Field Attachment	Dark-field Condenser(Dry)
Dark Field Attachment	Dark-field Condenser(Immersion)
