MOM.036002Ophthalmic Microscope, 1.9X-17.8X, 3.3X-31.2X
  • /usr/575/images/Products/Y/57518403.jpg
  • /usr/575/Picture/Y/11415.jpg
  • /usr/575/Picture/Y/11416.jpg
  •

MOM.036002 Operation Microscopes using fiber-optic cable for coaxial illumination, have different working distance and magnification. They are featured for flexible handling and easy operation. They can be used for micro-operation in ear-nose-throat, ophthalmology, gynecology and surgery.

Specification
MOM.036002-FSB
MOM.036002-FTB
MOM.036002-FRB
Total magnification
1.9X-17.8X
3.3X-31.2X
Head
Straight
45°Tilted
Adjust from -40°to 80
Demonstrator Optional YES
Eyepiece 12.5X,,Interpupillary Distance: 50mm-80mm;Diopter: ±5D
Magnification Changer 5-step magnification change: 0.4x, 0.6x, 1x, 1.6x, 2.5x
Focal Length Of Objective 200mm & 300mm
Working Distance 200mm & 300mm
Fine Focusing Range 20mm
Filter Built-In Green Filter
Balancing Arm Counterweight Adjustable
Illumination 21V150W Halogen Lamp, Brightness Adjustable
Optic Fiber Cable 130cm
TV adapter C-mount 1/3 inch CCD Attachable
Stand Long Column Fitted On The Round Base With 5 Jaws

Item
MOM.036001 Optional Accessory
Beamsplitter MOM.036001-BS
Demonstrator MOM.036001-DS
TV Adapter MOM.036001-TA
Photo Adapter MOM.036001-PA
