MAC.003077Digital Camera, CMOS, 3.0M, USB2.0
  • /usr/575/images/Products/Y/57518012.jpg
  • /usr/575/Picture/Y/11025.jpg
  •
  •
  • High sensitivity, low noise, excellent color correction
  • USB2.0 live video transfer
  • Compatible with Windows 2000/ XP/ Vista/Win7
  • Easy and fast software installation
  • User-friendly and sophisticated image processing applications
  • Premium optical lens adapter
Specification
MAC.003077
Image Sensor
3.2MP 1/2 inch CMOS Image Sensor(4:3)
Active pixels
2048×1536
Pixel size
3.2μm3.2μm
Frame rate
9fps@2048×1536
Shutter type
Electronic rolling shutter (ERS)
Sensitivity
>1.0 V/lux-sec (550nm)
Dynamic range
61dB
SNR
43dB
Image Output
USB2.0, Directshow and Twain
Operating System
Windows 2000/ XP/ Vista/Win7/Win 8/Mac
Operating temperature
0°C ~ 60°C
Packaging Contents
Software
ScopeImage 9.0
Cable
USB2.0 cable
Adapters
Eyepiece tube adapters Ф23.2/ Ф30 OR Ф23.2/ Ф30.5

Item
Optional Accessories
Software
ScopeImage Advanced
Stage Micrometer
Calibration slide 0.01mm and 0.1mm
