Digital Camera,CCD,5M,GigE_IHPVISION:Microscope,Digital Vision

MAC.031003Digital Camera,CCD,5M,GigE

2/3" SONY CCD Sensor 5.0M
Gigabit Ethernet Output Interface, data transfer speed is better than USB2.0 and USB3.0
Connect to computer distance more than 100m without attenuation
Support All Windows System 32/64 Bits Version

Specification	MAC.031003
Senser	2/3" SONY Color CCD, ICX625
Pixels	5M
Max Resolution	2448*2050
Pixel Size	3.45µm×3.45µm
Max FPS	15fps (2448*2050)
Output Digi	8 Bits
Exposure	Frame Exposure
SNR	38.1dB
Dynamic Range	70.1dB
Sensititive (550nm)	1.4V/lux-sec
I/O Control	2 Way Input, 2 Way Output
Output Data Interface	1000M Gigabit Ethernet Interface, Fit 100M Ethernet Too,Connect to computer distance more than 100m without attenuation
Power Supply	USB Power Supply
Power	9~12V, External
Lens Mount	Standard C/CS Mount, Adjustable
System	Windows All System 32/64 Bits Version
Software Control Function	Driver one-touch auto-install; provide Windows SDK development kit (VC, VB, C #), support Labview, providing OCX controls; IP addresses by top software modification; supports multiple cameras simultaneously, switching work; application layer can switch the display frame rate; overall gain, adjustable contrast; auto white balance, auto exposure
Signal Control	4 I / O input (external trigger acquisition), 4-way I / O output (flash sync), I / O interfaces All optocoupler isolation; With anti-blink function; external trigger provides synchronous trigger, asynchronous trigger mode;
Product Size	585880mm
