MAC.031006Digital Camera,CMOS,3M,USB2.0
  • /usr/575/images/Products/Y/57518155.jpg
  • /usr/575/Picture/Y/11219.jpg
  •
  •

Applications: assembly line piece-line detection, license plate recognition capture, microscopic image acquisition and many other fields.

  • 1/2" SONY CMOS Sensor, 3.0M
  • USB2.0 Output Interface

Specification
MAC.031006
Senser

1/2" SONY Color CMOS Sensor

Pixels
3.0M
Max Resolution

2048*1536

Pixel Size
3.2μm×3.2μm
Max FPS
5fps (2048*1536)
Output Digi
8 Bits
SNR
43dB
Dynamic Range
61dB
Sensititive (550nm)
1.0V/lux-sec
Output Data Interface

USB 2.0

Power Supply
USB Power Supply
Lens Mount
C Mount
System

Windows 2000, WindowsXP,Windows 7,Windows Vista

Software
Support DirectShow , Twain and LAbview. Including OCX, SDK and Measuring Software
Other Function
Auto/Manual Black Balance
Product Size
50*50*46mm
