MAC.030003Digital Camera,5M CCD,GigE
  • /usr/575/images/Products/Y/57518382.jpg
  •
  •
  •
  • Low-cost, high-speed CCD image sensors
  • GigE interface,1000Mb/s
  • Ultra-compact 29 x 29 x 30 mm metal case, lightweight

The camera is designed to maximize usability, including the compact cast metal case, C-mount lens holder and ASA/ISO- compliant tripod mounting bracket, status LED and removable glass/IR filter system.

Specification
MAC.030003
Sensor
Sony ICX655 CCD, 2/3",Color
Pixel Size
3.45umX3.45um
Maximum Resolution
2448X2048
Shutter
Global Shu er
Maximum Frame Rates
8fps (@2448X2048)
A/D Converter
12bit
Video Data Output
8, 12, 16 and 24-bit digital data

Image Data Formats

Y8, Y16, Mono8, Mono12, Mono16 (all models) RGB, YUV411, YUV422, YUV 444, Raw8, Raw12, Raw16 (color models)
Partial Image Modes
Pixel binning and region of interest (ROI) modes
Image Processing
Gamma, lookup table, hue, saturation, and sharpness
Gain
0 dB to 24 dB, Automa c/Manual/One-Push Gain modes
Gamma
0.50 to 4.00
White Balance
Automatic/Manual modes, programmable via software
Color Processing
On-camera in YUV or RGB format, or on-PC in Raw format
Digital Interface
Gigabit Etherneti nterface with screw locks for camera control and data
Transfer Rates
10/100/1000 Mbit/s
GPIO
8-pin Hirose HR25 GPIO connector for power, trigger, strobe, PWM, and serial I/O, 1 opto-isolated input, 1 opto-isolated output, 2 bi-direc onal I/O pins
External Trigger Modes
IIDC Trigger Modes 0, 1, 3, 4, 5, 13 (FL3-GE-13S2 only), 14 and 15
Synchronization
Via external trigger or software trigger
Image Buffer
32 MB frame buffer
Memory Channels
2 memory channels for custom camera settings
Flash Memory
1 MB
Dimensions
29 x 29 x 30 mm excluding lens holder (metal case)
Mass
58 g
Power Consumption
12-24 V, <2.5 W, via GPIO
Camera Specification
GigE Vision v1.2
Camera Control
Via FlyCapture SDK, CSRs, or third party software
Lens Mount
C-mount
Temperature
Operating: 0° to 45°C; Storage: -30° to 60°C
Emissions Compliance
CE, FCC, RoHS
Operating System

Vista or Windows 7
