MAC.030004Digital Camera, 5.0M CCD, GigE
  • /usr/575/images/Products/Y/57518383.jpg
  •
  •
  •
  • Low-cost, high-performance CCD camera
  • GigE interface,1000Mb/s
  • High FPS,up to 15fps@2448X2048

The camera is designed to maximize usability, including the compact cast metal case, C-mount lens holder and ASA/ISO- compliant tripod mounting bracket, status LED and removable glass/IR filter system.

Specification
MAC.030004
Sensor
Sony ICX625 CCD, 2/3",Color,progressive scan
Pixel Size
3.45umX3.45um
Maximum Resolution
2448X2048
Shutter
Global Shu er
Maximum Frame Rates
15fps (@2448X2048)
A/D Converter
14bit
Video Data Output
8, 12, 16 and 24-bit digital data

Image Data Formats

Y8, Y16, Mono8, Mono12, Mono16 (all models) RGB, YUV411, YUV422, YUV 444, Raw8, Raw12, Raw16 (color models)
Partial Image Modes
2x2 and 4x4 pixel binning and region of interest modes
Gain
automatic / manual / one-push gain modes, programmable via software, -2.6dB to 24dB in 0.04dB increments
White Balance
Automatic/Manual modes, programmable via software
Digital Interface
Gigabit Ethernet1000 Mbit/s
Partial Image Modes
2x2 and 4x4 pixel binning and region of interest modes
GPIO
8-pin Hirose HR25 GPIO connector for power, trigger, strobe, PWM, and serial I/O, 1 opto-isolated input, 1 opto-isolated output, 2 bi-direc onal I/O pins
External Trigger Modes
External hardware or software trigger
Multiple exposure, bulb shutter, multi-shot, and overlapped trigger modes
Synchronization
Via external trigger or software trigger
Image Buffer
32MB frame buffer, 512 KB non-volatile data flash
Memory Channels
2 memory channels for custom camera settings
Dimensions
44 x 29 x 58 mm excluding lens holder (metal case)
Mass
86 g
Power Consumption
12-24 V, <4.7 W
Camera Specification
GigE Vision v1.2
Camera Control
Via FlyCapture SDK, CSRs, or third party software
Lens Mount
C-mount
Temperature
Operating: 0° to 45°C; Storage: -30° to 60°C
Emissions Compliance
CE, FCC, RoHS
Operating System

Vista or Windows 7
