MAC.002021Linear Digital Camera, 3.6K CCD, USB2.0
  • /usr/575/images/Products/Y/57518430.jpg
  •
  •
  •
  • Linear USB2.0 CCD camera with C-mount, f-mount, and M72x0.75 photography standards
  • 3648 pixel silicon linear CCD array
  • 16-Bit A/D converter for high intensity resolution
  • External trigger capability
  • Board-level camera, ideal for OEM applications
  • No external power supply required
  • High scan rate (up to 120 scans/second)
  • SDK for user applications
  • Demo graphical user interface
  • Compatible to Windows XP, Vista and 7/8(32 or 64 bit)

Specification
MAC.002021
Sensor
TCD1304 (1D Toshiba CCD)
Senser Size
29.184mm
Pixel Size
8μm x 200μm
Max.Resolution
3648 Pixels
Spectral Range
300-1000nm
A/D Converter
16-bit to PC
Sensitivity
200 V/lx.s with Daylight Fluorescent Lamp
Output Rate
1.0MHZ
Exposure Range
3.8-4000ms
External Trigger
Supported
Capture/Control API
SDK and Example Code
Capture Mode
Single Camera Multiple Instance and Multiple Cameras Supported
Host Interface
USB2.0
Power Supply
Over USB Port
Capture Mode
Still Picture and Video
Color Rendering Technique
Ultra FineTM Color Engine
Lens Mount
M42
Operating System
Microsoft Windows XP / Vista / 7 (32 & 64 bit)
CPU: Equal to Intel Core2 2.8GHz or Higher
Memory:2GB or More
USBPort:USB2.0 High-speed Port
Remarks
Actual frame rates on your computer depend on the hardware and operating system used
Operating Temp.
-30~70℃
Storage Temperature
-40~85℃
Operating Humidity
30%~80%RH
Storage Humidity
10%~60%RH
Package Box
140mmx140mmx80mm, 0.5Kgs
