MAC.002017Digital Camera, 5.2M, USB2.0, Cooled CCD
  • /usr/575/images/Products/Y/57518825.jpg
  • /usr/575/Picture/Y/11540.jpg
  •
  •
  • C-Mount camera with SONY EXview or Super HAD CCD sensor
  • Well-designed high-performance TE-cooling with heat pipe heat sink structure
  • Up to 20 degrees temperature drop ensures high quality image with lower noise
  • Supporting up to 4'long time exposure
  • USB2.0 interface ensuring high speed data transmission
  • Ultra-Fine color engine with perfect color reproduction capability
  • With advanced video & image processing application ToupView
  • Providing Windows/Linux/OSX multiple platform SDK
  • Native C/C++, C#, DirectShow, Twain Control API
Specification
MAC.002017
Sensor Resoution 5.2M,2448x2050
Sensor Type Color CCD,ICX655AQ
Sensor Size 2/3"(9.93x8.70)
Pixel Size 3.45x3.45um
Frame Rate 4.3@2448x2050
10.5@960x720
Binning 1X1
Exposure 0.12ms~240s
Spectral Range 380-650nm (with IR-filter)
White Balance ROI White Balance/ Manual Temp-Tint Adjustment
Color Rendering Technique Ultra Fine Color Engine
Capture/Control API Native C/C++, C#, Directshow, Twain, Labview
Recording System Still Picture and Movie
Cooling System* TE-Cooled CCD - 20 °C below Ambient Temperature
Operating Temperature -10℃~ 50℃
Storage Temperature -20℃~ 60℃
Operating Humidity 30~80%RH
Storage Humidity 10~60%RH
Power Supply DC 5V over PC USB Port
Operating System Support Microsoft Windows XP/ Vista / 7 /8 (32 & 64 bit)
OS X (Mac OS X), Linux
Lens Mount C-Mount
PC Requirements CPU: Equal to Intel Core2 2.8GHz or Higher
Memory: 2GB or More
USB port: USB2.0 High-speed Port
CD-ROM
Display: 17" or Larger
