MAC.026003Digital WiFi Camera, 5M, 720P, CMOS
  • /usr/575/images/Products/Y/57519515.jpg
  • /usr/575/Picture/Y/11654.jpg
  • /usr/575/Picture/Y/11655.jpg
  •
  • It can put the observed imaging into computer and make an analysis,measurement,and statistics.
  • It improves the practical connotation of traditional optical instrument. Cooperating modern equipment made vas and tedious work become more interesting, relaxed, and effective. When we have it, microscope world is not tiny any more, and transient change will be forever. Our education and study will be more convenient and effective.

5.0M CMOS High Resolution WiFi Digital Camera,1/2.5" CMOS, True Color,720P.

  • MAC.026003 includes the standard configuration:Camera,software/App CD,warranty card.
  • MAC.026003 –M includes the standard configuration,also includes: 1X Dia.23.2mm Ring for biological microscope eyepiece tube, Dia.30mm and 30.5mm Ring for stereo microscope eyepiece tube.
  • MAC.026003 –P includes the standard configuration,also includes:0.5X Lens Dia 23.2mm is equipped with rubber ring to make adapter ring very stable avoid detachment troubles, Dia.30mm and 30.5mm Ring for stereo microscope eyepiece tube.
Specification
MAC.026003
MAC.026003-M
MAC.026003-P
Connecting C-Mount C-Mount, Including Adapter Ring 23.2mm(1X), 30mm,30.5mm C-Mount, Including
Adapter Ring 23.2mm(0.5X), 30mm,30.5mm
Digital Camera
5.0M CMOS High Resolution Digital Camera
Sensor 1/2.5" CMOS, True Color
Senser Size 5.70mm(H) x 4.28mm(V), diagonal7.13mm
Pixel Size
2.2x2.2μm
Resolution 2592*1944 Max.
Spectral region 380-650nm (with IR-cut Filter)
Working Modes A.USB mode
B.WiFi mode
Frame Rate
  • YUV output:
    640x480@30fps,800x600@20fps,1280x960@10fps,1280x720@10fps,2592x1944@5fps
  • MJPG output:
    640x480@40fps,800x600@40fps,1280x960@40fps,1280x720@40fps,2592x1944@15fps
A/D switch 12-bit on chip,10-bit to pc
SN Ratio 38.1dB
Dynamic Range 70.1dB
White Balance Automatic White Balance/Automatic Exposure
Exposure Manual/Auto, .9ms - 320ms
Focus mode Manual fine adjust, big range auto-focus
Observe methods Still picture and video in real time
Snapshot control API Native C/C++, C#, Direct Show, UVC
Wireless
parameters
wireless protocol: IEEE 802.11b/g/n frequency range:2.4000--2.4835GHz
transmit bandwidth :150Mbps
Operating System Microsoft Windows XP / Vista / 7 (32 & 64 bit)
CPU: Equal to Intel Core2 2.8GHz or Higher
Memory:2GB or More and CD-ROM
Operation Software Windows: Micro Cam; Android & IOS: Ucam
Software language Chinese, English, Japanese,Swedish,Deutsch, accept OEM languages
Hardware
requirement
CPU: equivalent to Intel Core2 1.6GHz or higher Memory :2GB or higher
USB port :USB2.0 High-speed port DVD-ROM(required when installing software)
OS requirement Microsoft Windows XP / Vista / 7 / 8 (32 & 64 bit)
MAC OS X (wireless working mode) IOS5/IOS6 (wireless working mode)
Power supply Built-in lithium battery(4500 mAh);
DC 5V USB power supply by PC; External DC 5V 1.5A adapter
Package size
Single weight :1.5kg, dimension: 26x 9x 6cm
