MAT.041006Digital LCD PAD, Windows10, 11.6''LCD, 16M, HDMI
  • /usr/575/images/Products/Y/57519727.jpg
  • /usr/575/Picture/Y/11664.jpg
  • The device can be widely used in scientific research, industry, teaching and so on,powerful performance, reliable quality
  • 11.6 Inch (Diagonal) IPS liquid crystal display, resolution 2048*1536
  • Built-in CMOS color camera, real-time display, support treatment, storage, network and other functions. 16M camera resolution.
  • The system has strong scalability, can choose a variety of accessories according to different needs, such as bright field, dark field, phase contrast, polarization etc.
  • The operating system uses the Windows10.

If you are interested in 9.7’’PAD uses Andriod System, pls choose MAT.041007

MAT.041006 11.6 " LCD Pad with Windows10 System, 16M
Specification of LCD PAD
LCD Screen 11.6" LCD Resolution 2048*1536
Data Storage TF Card Slot, Support Max 32GB
Data Interface HDMI,USB 2.0, LAN,WIFI
Operation System Windows 10 System, Multi Language
Power Wide Voltage AC 100~240V, DC 12V with External Power Adaptor
WIFI Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 18*28cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Sensor 1/2 33" CMOS Color Panasonic CMOS
16M Pixels, 4608*3456
Pixel Size 2.8um*2.8um
Frame Rate 5fps@4608*3456
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount
