MLP.003054LCD Polarizing Microscope, 9.7'' LCD, 5M, 40~1000X
  • /usr/575/images/Products/Y/57519035.jpg
  •
  •
  •

Transmit Polarizing Microscope, Newly designed with comfortable operating with ergonomic structure, with better illumination, convenient replacement of attachment with sliding-in center adjustable condenser.

  • 9.7’’ LCD Screen,resolution 1024*768
  • 5.0M CMOS Image Sensor built-in
9.7" LCD Pad with Andriod System of MLP.00354
Specification of LCD PAD
LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU 1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System
RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser 1/2.5" CMOS, Color, Aptina MT9P001
Resolution
5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
Main Body of MLP.003054
Head
Seidentopf Trinocular Head, 30° Inclined, Interpupillary 48~75mm, Diopter Adjustable
Optical System
Infinite optical system
Eyepiece
Plan Eyepiece EW10x/22mm, Eyepiece Tube Dia.30mm
Plan Eyepiece With Scale of Crosshair
Plan Eyepiece With Cross
Plan Eyepiece With Gridding
Objective
Strainfree Infinity Plan Achromatic Objective 4x/0.10/∞/- W.D.17.3mm
Strainfree Infinity Plan Achromatic Objective 10x/0.25/∞/0.17 W.D.10mm
Strainfree Infinity Plan Achromatic Objective 40x/0.65/∞/0.17 W.D.0.54mm
Strainfree Infinity Plan Achromatic Objective 100x/1.25/∞/0.17 W.D.0.13mm
Nosepiece
Backward Quintuple Nosepiece, Center Adjustable
Analyzer

1) 360° Dial Rotation Analyzer, Minimum Scale Reading 0.1° (Vernial Scale)
2) Switch Between Orthoscopic And Conoscopic Observation
3) Bertrand Lens Postion Adjustable
4) Optical Compensator: λ Slip (First Class Red), 1/4λ Slip, Quartz Wedge

Focusing
Coaxial Coarse & Fine Adjustment, Focusing Range 32mm, Fine Division 0.001mm, Coarse Stroke 37.7mm Per Rotation, Fine Stroke 0.1mm Per Rotation
Stage

Polarizing Rotatable Stage, Dia.170mm, Center Adjustable
360° Scale, Minimum Division 1°
Minimum Reading 6' By Means of Vernial Scale
45° Click Stop Knob

Condenser
Strainfree Swing Condenser N.A.0.95/0.25
Polarizer
360° Rotatable, 0° Position Adjustable
Filter
Blue Filter, Dia.45mm
Illumination
Transmit Illumination Halogen Lamp 24V100W, Brightness Adjustable
