MDM.019004Digital Portable Metallurgical, 5.0M, 100X~500X
  • /usr/575/images/Products/Y/57518706.jpg
  •
  •
  •

This is an ideal portable metallurgical scope for industry inspection.Used in oil and gas pipelines, bearings, foundry industry, boilers and other industries, is indispensable microstructure and surface inspection tool.

  • Coaxial LED lighting can work continuously for 48 hours
  • Being intersected polarizing device
  • 5.0M Camera
Specification
MDM.019004   Digital Portable Metallurgical Kits
Total Magnification 100X~500X
Eyepiece
WF10X/FN18, Dia 23.2

LWD Plan Objective
(no cover glass)

 PLL 50X/0.65 WD=0.5mm
PLL 10X/0.25 WD=7.3mm
Mechanical Tube Length
160mm
Focusing
Coaxial coarse/fine focus system, range:36mm
Polarizing Kits Polarizer and Analyzer
Light Source Coaxial illumination, build-in LED rechargeable, brightness adjustable
Digital Camera
Pixel
5.0M
Max Resolution
2592x1944
Pixel Size
2.2um x 2.2um
CCD Sensor
1/2.5"
Sensor Size (mm)
5.70x4.28
Sensitivity(@550nm)
0.53v/lux-sec
DynamicRange
66.5dB
SN Ratio
40.5dB
Frame Rate
5fps;18fps;60fps
Binning
1x1;2x2;4x4
Exposure
0.21~2000ms
Output
USB 2.0,support No driver required
A/D Conveter
12-bit, 8-Bit R.G.B to PC
White balance
Auto/Manual
Scan Mode
Progressive
Packing info Portable aluminium case

Item
Optional Accessories
Digital Adapter
For Canon EOS Digital Camera
LWD Plan Objective
Non-cover glass
PLL20 WD=8.6mm

PLL60 WD=1.34mm
PLL80 WD=0.96mm

PLL100 WD=0.4mm
