MDT.0470013D Microscope, 0.7X~4.5X, 0°/25°/45°/55°
  • /usr/575/images/Products/Y/57520005.jpg
  •
  •
  •

Widely used in electronics, machinery and other industries

  • High quality optical system, high resolution, large field of view and high zoom ratio
  • Easy operation, automatic focus, automatic zoom
  • Angle observation device, to achieve 3D image effect, provide 25 degrees, 35 degrees and 45 degrees variable angle observation, can be observed from different angles.You can observe the three-dimensional components and hole depth from different angles
Specification
MDT.047001   3D Microscope
Host zoom range 0.7X~4.5X
Zoom Ratio 1:6.5
Viewing Angle 55°
Working Distance 45mm
Maximum comprehensive magnification 2.325~540X (In the two dimensional observation when selecting the high magnification objective ,and use 1/3 inches CCD and 14 inch monitor )
Maximum view angle of object 2ω=19.5°
View angle of image 2ω=7.6°
Maximum moving range of XY platform x=300mm, y=250mm
The maximum usable size of the stage 440mm×290mm
Platform size 440mm×290mm×36mm
Input voltage 85-240V,50/60HZ

Item
Optional Accessories
Viewing angle 0°,25°,45°
Circuit board support frame 40mm
Bottom light source 2X2 inch luminous area, LED or cold light source (Stage with light source for optional)
